Handheld Laser Rust Removal Paint/Coating/Oxide 30W 50W Convenient
Outdoor Backpack Clean Laser Machine
Description:
QA-LC30B is a backpack laser rust removal machine. It is free to
wrok outdoor or in air on platform, like on bridge, buliding walls,
tower etc.
For some outside cleaning job, it is not easy to carry a big
machine with the operator. So backpack laser cleaning machine is
the best choice. Easy to carry and operation.Free to move anywhere
you like.
It can remove the grease, dirt, coating, paint, rust, residue,
oxide layer, and other target materials with high efficiency, high
performance, low cost and without harm to the base material. It can
meet the cleaning requirements of complex modeling and fine
positioning in the industrial processing field, achieving a cleaner
cleaning effect and a lower overall production cost.
Product features:
1. Free to wrok outdoor;
2. Suitable for cleaning different materials;
3. Different languages to choose from;
4. None pollution;
5. Expansibility;
6. No damage to the base material;.
7. Easy to operate,
8. Convenient to work in air on platform
Specifications:
Backpack
Laser Rust Removal Machine HQ.pdf
| Model | QA-LC30B | QA-LC50B | QA-LC100B |
| Laser source | Fiber | Fiber | Fiber |
| Laser Power3 | 0W | 50W | 100W |
| Fiber cable length | 2 meters | 2 meters | 2.5 meters |
| Laser Wavelength | 1064nm | 1064nm | 1064nm |
| Pulse Energy | 0.6 mJ | 1 mJ | 1.5 mJ |
| Pulse frequency | 30-60KHz | 1-2000KHz | 1-2000KHz |
| Scanning speed | 0-7000mm/s | 0-7000mm/s | 0-7000mm/s |
| Cooling | Air cooling | Air cooling | Air cooling |
| Dimension | 400*180*450 mm | 400*180*450 mm | 500*200*550 mm |
| Weight | 18Kg | 20Kg | 36Kg |
| Beam width | 10-70mm | 10-70mm | 10-100mm |
| Optional | Manual | Manual | Manual |
| Temperature | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ |
| Voltage | Single Phase 220V, 50/60HZ | Single Phase AC 220V,2.5A | Single Phase AC 220V 4.5A |
Comparison with traditional cleaning methods:
| Comparisons | Laser Cleaning | Chemical Cleaning | Mechanical Grinding | Dry ice cleaning |
| Methods | non-contact cleaning | contact cleaning | Abrasive contact cleaning | non-contact cleaning |
| Harm to base material | None | Yes | Yes | None |
| Efficiency | High | Low | Low | Mid. |
| Consumable | Power | Chemical Detergent | Abrasive paper, grinder, abrasive stone | Dry Ice |
| Washing result | Very good, very clear | Medium, uneven | Medium, uneven | Good, uneven |
| Precision Washing | Accuracy controllable. High precision | Uncontrollable, low precision. | Uncontrollable, medium precision. | Uncontrollable, poor precision. |
| Safety/Environment | No pollution | Chemical pollution | Dust pollution | No pollution |
| Operation | Easy to operate, portable or automation optional. | Complicated process, higher technical requirement of the operator.
Pollution prevention measures required. | Need more time & manpower. Pollution prevention measures required. | Easy to operate, portable or automatic. |
| Investment | High investment on machine. But no consumable, low maintenance cost | Low investment on machine. But expensive consumables | Medium investment on machine. High man-power cost. | Medium investment on machine. High consumable cost.
|
Application scope:
Industries: air plane and ship metal surface derusting , paint
removal; building surface dirt cleaning;
chip surface cleaning of micro electricy
FAQ
1 Q: What is the warranty of the backpack laser rust removal?
A: The warranty is 24 months, but we offer whole life after-sale
service.
2 Q: What is your payment terms?
A: T/T, L/C, Westen Union, etc.
3 Q: What is your after-sale service?
A: Engineers can offer oversea services and we can also offer
online service, using online chatting tools like Whatsapp to talk
with customers directly for all questions .
4 Q: How is the quality of the machine?
A: Germany high technoloy with good quality.
5 Q: How is the operation of the machine?
A: We offer operation manual and videos, show you how to operate
the machine.
We can also send engineers to your factory for training. Or you can
send worker to gain training in our factory directly.
