Fiber Metal Laser Cutting Machine 1000W For Carbon Sheet
Overview
Rigid-FL1000F-1530 Fiber Optic Sheet Metal Laser Cutting Machine
has equiped with a a big sealed working house, which can protect
the worker during cutting operation. The laser power is very high,
reaching 2000W, which can cut very thick metal sheet.
The laser cutter consists of 5 parts ,the machine bed host,
electrical control, water cooling unit, air cooling system and
Exhaust system.
The machine bed host is the main part of the whole laser cutting
machine. Cutting function and cutting accuracy of laser cutting
machine are realized by it.
The electrical control system is an important part of ensuring that
all kinds of graphics running tracks, which is composed of the CNC
and the low-voltage electric system.
Other auxiliary peripheral equipment including large water chiller,
cooling system, exhaust system and power supply
Advantages
1. Great Performance: Identical cutting quality on any cutting
point is realized through fiber transmission.
2. High Efficiency: The rapid cutting speed is two times higher
than that of CO2 laser machine.Its use-cost is low.
3. Low Consumption of Gas: Laser cutting does not make any gas
because of the specific cutting technology on steel plate.
4. Low Consumption of Energy: It is environment-protecting and
energy-saving.Its power consumption is reduced by 20%-30% compared
with that of CO2 laser machine.
5. Maintenance-free: Reflecting lens is not needed for fiber
transmission.Much time is saved when optical path is adjusted.It is
maintenance-free
6. Install Proportional Valve: Use software to change the air and
control the air pressure automatically, no need to change the air
manually, it can save you much time;
7. Stable working table: Use 8mm thick steel side board, around 3.5
tons in weight;
8. Dual drive, aging treatment, stress relief test to ensure long
time fast running without changing shape;
Parameters
| Model | Rigid-FL1000-3015 |
| Laser source | Fiber laser (IPG) |
| Laser Power | 1KW |
| Laser Wavelength | 1070nm |
| Max working area | 3000x1500mm |
| Working table | Single (double exchange tables optional) |
| Z axis movement | 100mm |
| Positioning accuracy | ±0.01mm |
| Repeating accuracy | ±0.02mm |
| Max cutting speed | 18m/min |
| Max cutting thickness | 1-16mm according to materials |
| Cooling | Water cooling |
| Laser Cutting Head | Auto focus Raytools from Swiserland |
| Servo Motor & Driver | YASKAWA From Japan |
| Reducer with Gear | Shimpo from Japan |
| Rack Pinion | Hiwin from Tanwan(World Brand) |
| Linear Guiderail | Hiwin From Tanwan(world Brand) |
| Control System | CyperCut8000 from Bochu China |
| Oil Lubricated | Automatic lubricated |
| Gantry System | Steel gantry |
| Pneumatic Control | SMC from Japan |
| Gas controller | Double |
| Machine Dimension | 4650*2300*1750 mm |
| Weight | 2900Kg |
| Power Protection Level | IP54 |
| Voltage | Three Phases 380V, 50HZ
|
Cutting parameter
| Material / Laser Power | 500W | 750W | 1000W | 2000W | 3000W | 4000W |
| Carbon Steel | 6mm | 8mm | 10mm | 16mm | 20mm | 22mm |
| Stainless Steel | 3mm | 4mm | 6mm | 10mm | 12mm | 15mm |
| Aluminum | 1mm | 3mm | 4mm | 6mm | 8mm | 10mm |
| Brass | 1mm | 2mm | 4mm | 6mm | 8mm | 8mm |
| Copper | 1mm | 2mm | 3mm | 4mm | 5mm | 6mm |
| Galvanized Steel | 1mm | 2mm | 4mm | 6mm | 8mm | 10mm
|
Gantry type mechanical structure, compact taking up small area A,
Five tons in weight, 16mm Thickness square steel tube and 25mm(T)
steel panel. B, Beautiful and dignified in appearance, industry
technics and aging treatment; high working efficiency and steady
performance, it can obtain more than 10 years lifespan. Working table 1,High precision CNC fixed working table with Rack
Pinion contruction; 2, Special designed small pneumatic wheel carriers ,the metal sheet
to be cut may slide along the machine body for easy loading;
3,Strip working table; Aluminum material, put cutting sheet on it . |
500W/1000W/2000 Fiber Laser Generator Ytterbium Fiber Laser, Low
Energy Consumption: Save energy and protect environment.
Photoelectric conversion rate is up to 25-30%. Low electric power
consumption, it is only about 20%-30% of traditional CO2 laser
cutting machine. Lifetime is more than 100,000 hours, almost free
maintenance. 1. Laser output power: 500W/1000W 2. Laser wavelength: 1070nm 3. Output energy regulating: 10%~100% 4. Input Power: less than 1.5KW-1.9KW 5. Working temperature: 16~35ºC |
Application
It has been widely used in the field of aviation and space, weapon,
warship, petrifaction, medical, instrument, micro-electron, auto
mobile car and so on.
Machine outlook
FAQ
1 Q: What is the warranty of 100W laser rust removal machine?
A: The warranty is 1 year, but we offer whole life after-sale
service.
2 Q: What is the payment terms do you have?
A: T/T, L/C, Westen Union, etc.
3 Q: What is the after-sale service?
A: Engineers can offer oversea services and we can also offer
online service, using online chatting tools like Whatsapp to talk
with customers directly for all questions .
4 Q: How is the quality of the machine?
A: Germany high technoloy with perfect quality.
5 Q: How is the operation of the laser rust removal machine?
A: We offer operation manual and videos, show you how to operate
the machine.
We can also send engineers to your factory for training. Or you can
send worker to gain training in our factory directly.
