100W Laser Surface Cleaning Machine for rust removal
Description:
QA-LC100 laser rust removal machine adopt a 100W Mopa fiber laser
source, mainly used for ship,boat,Car cleaning.
The whole surface or the designated part of the paint off, the
welding department to remove paint inspection, the removal of
oxides, oil, grease and production residues;Die Cleaning, welding
surface pretreatment, metal surface roughness, natural rock
cleaning, metal and glass surface coating removal, the whole
surface off paint;
New welding point Preparation, metal surface roughness, rapid
dust/oxide, oil, grease and production residues; industrial,
military and shipbuilding industry-product coating high-speed
cleaning, NDT welding inspection coating cleaning;
Product features:
1. Low cost;
2. Quick investment recovery;
3. No sandblasting sand grains or chemical agents;
4. No erection time for equipment use;
5. No noise;
6. Few maintenance requirements.
7. Few maintenance requirements.
Specifications:
Introduction of Laser Cleaning
Technology A.pdf
QA-LC100
Laser Cleaning Machine for rust removal.p...
| Model | QA-LC60 | QA-LC100 | QA-LC200 | QA-LC500 |
| Laser source | Fiber | Fiber | Fiber | Fiber |
| Laser Power | 60W | 100W | 200W | 500W |
| Fiber cable L | 3 M | 3 M | 5 M | 10M |
| Pulse Energy | 1.5 mJ | 1.5 mJ2 | mJ | 50 mJ |
| Wavelength | 1060nm | 1060nm | 1060nm | 1060nm |
| Frequency | 50-500KHz | 50-200KHz | 20-50KHz | 10-50KHz |
| Clean speed | ≤5 M²/Hour | ≤10 M²/Hour | ≤15 M²/Hour | ≤50 M²/Hour |
| Scann speed | 0-7000mm/s | 0-7000mm/s | 0-7000mm/s | 0-7000mm/s |
| Cooling | Air cooling | Air cooling | Air cooling | Water cooling |
| Dimension | 450*300*500 | 650*350*560 | 900*600*1100 | 1600*1100*1800 |
| Weight | 30Kg | 36Kg | 120Kg | 300Kg |
| Beam width | 10-100mm | 10-100mm | 10-100mm | 10-100mm |
| Optional | Manual | Manual | Manual | Manual |
| Temperature | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ |
| Voltage | Single Phase 220V, 50HZ | Single Phase 220V, 50HZ | Single Phase 220V, 50HZ | Single Phase 220V, 50HZ |
Application field:
Small area cleaning and paint removal treatment, welding surface
pretreatment, food line cleaning, printing wheel cleaning, precise
position/size paint treatment, restoration of monuments, rust/oxide
removal;
The whole surface or the designated part of the paint off, the
welding department to remove paint inspection, the removal of
oxides, oil, grease and production residues;
Die Cleaning, welding surface pretreatment, metal surface
roughness, natural rock cleaning, metal and glass surface coating
removal, the whole surface off paint;
Improve the bonding of welding surface pretreatment;
New welding point Preparation, metal surface roughness, rapid
dust/oxide, oil, grease and production residues; industrial,
military and shipbuilding industry-product coating high-speed
cleaning, NDT welding inspection coating cleaning;
Comparison with Traditional Clean Methods:
| Comparison | Laser Cleaning | Chemical Cleaning | Mechanical Grinding | Dry ice cleaning |
| Washing Methods | non-contact cleaning | contact cleaning | Abrasive contact cleaning | non-contact cleaning |
| Harm to base material | None | Yes | Yes | None |
| Washing Efficiency | High | Low | Low | Mid. |
| Consumable | Power | Chemical Detergent | Abrasive paper, grinder, abrasive stone | Dry Ice |
| Washing results | Very good, very clear | Medium, uneven | Medium, uneven | Good, uneven |
| Precision Washing | Accuracy controllable. High precision | Uncontrollable, low precision. | Uncontrollable, medium precision. | Uncontrollable, poor precision. |
| Safety/Environment | No pollution | Chemical pollution | Dust pollution | No pollution |
| Operations | Easy to operate, portable or automation optional. | Complicated process, higher technical requirement of the operator.
Pollution prevention measures required. | Need more time & manpower. Pollution prevention measures required. | Easy to operate, portable or automatic. |
| Investments | High investment on machine. But no consumable, low maintenance cost | Low investment on machine. But expensive consumables | Medium investment on machine. High man-power cost. | Medium investment on machine. High consumable cost. |
FAQ
1 Q: What is the warranty of 100W laser rust removal machine?
A: The warranty is 1 year, but we offer whole life after-sale
service.
2 Q: What is the payment terms do you have?
A: T/T, L/C, Westen Union, etc.
3 Q: What is the after-sale service?
A: Engineers can offer oversea services and we can also offer
online service, using online chatting tools like Whatsapp to talk
with customers directly for all questions .
4 Q: How is the quality of the machine?
A: Germany high technoloy with perfect quality.
5 Q: How is the operation of the laser rust removal machine?
A: We offer operation manual and videos, show you how to operate
the machine.
We can also send engineers to your factory for training. Or you can
send worker to gain training in our factory directly.
