Product Description:
100W 200W 300W 500W 1000W Rust Removal Laser Cleaner
There is oxidation and corrosion when metals meet oxygen and water
vapor in air. It will greatly damage the metal work-piece and the
rust will spread from outside to inside and become worse and worse
as time goes on, until the whole work-piece is totally corrupted.
So rust removal is extremely important. Laser rust removal uses not
chemical agents or mechanical polishing, so it is faster and safer.
Laser rust removal Machine is a new generation of industrial
surface cleaning laser system. It adopts the advanced laser source,
laser optical scanners and control system to meet the requirements
of metal surface cleaning process.
Advantages:
1. Versatility: Rust removal laser cleaners come in varying power
capacities ranging from 200W to 1000W. This versatility means that
they can be used to remove rust from a wide range of surfaces and
in different industries, from automotive to industrial
manufacturing.
2. Precision: Laser cleaning is a highly precise process that can
target rust and other surface contaminants without damaging the
substrate. This precision is essential for industries that rely on
high-quality finishes.
3. Efficiency: Laser cleaning is an incredibly fast process and can
clean large areas in a short amount of time. This efficiency can
help businesses increase their productivity and reduce downtime.
4. Safety: Unlike traditional cleaning methods that use abrasives
and chemicals, laser cleaning is a non-contact and non-abrasive
process that doesn't pose any health risks to operators. This makes
it a safer and more environmentally friendly cleaning solution.
5. Cost-effective: Although laser cleaning equipment can be
expensive initially, it is generally more cost-effective in the
long run than other cleaning methods. This is because it doesn't
require consumables like abrasives, and its efficiency helps
businesses save on labor costs.
6. Improved quality: Laser cleaning removes rust and other
contaminants without damaging the substrate, leaving a clean and
smooth surface. This can improve the quality of the finished
product and increase customer satisfaction.
Technical Parameters:
| Model | QA-LC100 | QA-LC300 | QA-LC500 | QA-LC1000 |
| Laser source | Fiber | Fiber | Fiber | Fiber |
| Laser Power | 100W | 300W | 500W | 1000W |
| Fiber cable L | 2-8 M | 2-8 M | 10-100M | 10-100M |
| Output fiber L | 5M | 5M | 10M | 15M |
| Pulse Energy | 1.5-10 mJ | 12.5mJ | 25 mJ | 50 mJ |
| Pulse width | 90-130ns | 120-140ns | 90-160ns | 90-160ns |
| Wavelength | 1060nm | 1060nm | 1060nm | 1060nm |
| Frequency | 10-50KHz | 10-50KHz | 10-50KHz | 10-50KHz |
| Clean speed | ≤20 M²/Hour | ≤30 M²/Hour | ≤60 M²/Hour | ≤100M²/Hour |
| Cooling | Water cooling | Water cooling | Water cooling | Water cooling |
| Dimension | 900*450*950mm | 900*450*950mm | 1120*600*1080mm | 1120*600*1080mm |
| Packing | 1000*650*1130mm | 1000*650*1130mm | 1200*680*1250mm | 1200*680*1250mm |
| Net Weight | 90Kg | 100Kg | 220Kg | 280Kg |
| Gross weight | 130kg | 140kg | 280kg | 340kg |
| Beam width | 10-110mm | 10-110mm | 10-170mm | 10-170mm |
| Optional | Manual/Auto | Manual/Auto | Manual/Auto | Manual/Auto |
| Temperature | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ | 5-40 ℃ |
| Humidity | <90% | <90% | <70% | <70% |
| Power | < 2500W | < 3000W | < 6000W | < 8000W |
| Voltage | Single Phase 220V,50/60HZ | Single Phase 220V,50/60HZ | Single Phase 220V,50/60HZ | Single Phase 220V,50/60HZ |
