CO2 laser engraving and cutting machine for Wood MDF Acrylic
nonmetal 600x400mm
Introduction
QA80-6040 CO2 laser engraving cutting machine is a small type laser
engraving machine working for not big workpiece and products.
Our precision manufactured lasers and laser systems deliver the
highest possible laser engraving performance on a wide variety of
materials including wood, glass, plastics, textiles and more. Laser
engraving is a non-contact process that will not affect the
integrity of the material.
CO2 laser cutting engraving machne is used specially for the
nonmetal art crafts, gifts and the engraving of bamboo products.
The mechanical structure is strong and stable, making the machine
to run at high precision. The electrical ability is stable, the
engraving speed is high, and the precision is high.
Its speed and accuracy are guaranteed by using gear grinding with
high precision,imported guide rail and laser cutting head under
strict assembly.
Features
1. User-friendly hermetic top and bottom exhaust suction system
ensures safe working conditions.
2. Synchronous belt drive and semi-closed-loop structure, ensures
high precision engraving and fast speed. (engraving speed up to
800-1000mm/s)
3. Equipped with 30W RF metal laser. Output beam of high quality,
excellent power stability, long life, low use-cost,
maintenance-free, and high efficiency.
4. There is no machine starting cost. Operation cost is low.
5. With CE Certificate
6. Available to work with Windows 7 32/64 bits
7. High engraving speed
8. Safe and durable circuit design.
Specification
| Model | QA80-1060 | QA60-9060 | QA60-6040 |
| Laser | CO2 glass sealed laser tube or RF metal sealed laser tube optional |
| Laser power | 60W/80W/100W/130W | 60W/80W/100W |
| Work platform size | 1000×600mm | 900x600mm | 600x400mm |
| Engraving speed | 1-1000mm/s |
| Cutting speed | 1-500mm/s |
| Worktable | honey-comb or slatted optional |
| Precision | ≤±0.025mm |
| Graphic format | PLT,BMP,DXF,DST,TIF |
| Working temperature | 0-45 degree C |
| Motor type | Stepper Motor |
| Water Cooling | Water chiller |
| The Whole Set | 1PCS CO2 laser cutting machine 1PCS Water chiller 1PCS Air pump 1PCS Fan blower |
| Spare parts | Laser tube, Focal lens, Reflector lens(3PCS) |
| Electricity | 220V/50hz/1kva 110V60HZ 220V60HZ |
Materials
| Items | Engraving | Cutting |
Fabric Denim , leather , polyester , cotton , nylon , pongee , suede , jeans ,satin , corduroy , chiffon , tulle , fleece | yes | yes |
| Wood Plywood , bamboo , veneer , mdf , polymeric materials | yes | yes |
Plastic PP , plastic , ABS plastic , PVC , pipe , polyester , sheet , insulation layer | yes | yes |
| Organic Acrylic , rubber , resin , epoxy | yes | yes |
| Paper Packaging materials , tin foil , card , cardboard , chipboard | yes | yes |
| Composite Double color plate organic board | yes | yes |
Stone Ceramic , tile , marble ,granite , slate , gravestone , porcelain , tombstone , ceramic plate | yes | no |
Other Nonmetals process materials , coating materials , plating materials , spraying materials | yes | no
|
Applications
Applicable to precision engraving on acrylic, wood, double color
plates, bamboo, marble, paper, leather and other non-metallic
materials.
The industries like advertising logo making, crafts& gifts,
crystal, relief sculpture, leather
&cloth, embroidery and decoration.
Samples
Configuration
Machine overlook
