    Diamond Rod Diode Jewelry Laser Welding Machine 100 J 220V 1-50HZ 1064nm

    Spot welding equipment for jewelry 300W diamond rod diode laser source


    Spot welding equipment overview


    Robot300J Spot welding equipment can weld almost all kinds of metal materials.

    Laser soldering machine is an of important applicable fields,whose processing type is heat transmission, processing work pieces surface by laser radiation , heat transmit from surface to bowel, by controlling laser width, energy, top power and repitition frequency to melt workpieces , form a special melting pool. Due to its special traits

    It is especially suitable for jewelry repairing, mould epairing and gol f epairing. The laser source is YAG laser , with lamp and diamond Rod .

    The Observing system is equipped with special-purpose microscope observing system with cross cursor.

    It has high speed electron flitting device to protect the operator's eyes from being hurt.


    Features


    1 adopting British imported ceramics condensation cavity

    2 Imported lens mirrors rod and Xenon lamp

    3 10X clear microscope

    4 life of condensation cavity are 8-10 years

    5 life of xenon light is more than 8000 thousands


    Parameter data sheet

    Jewelry Laser Welding Machine.pdf


    typeRobot300J
    Output laser power300W
    Energe110J
    Wave length1064nm
    Laser power supply4.5 KW
    Laser welding minimum melt pool0.1mm
    Laser pulse frequency1 - 50Hz
    Laser pules width≤20ms
    Port adjusting scope0.1~3.0mm
    Port size0.2~3.0mm
    Protective gasyes (N2)
    Power demand220V one-phase/50Hz/20A
    Figure size of systemLaser welder1150X650X1400mm
    Water chiller740X600X1090mm

    Diamond Rod Diode Jewelry Laser Welding Machine 100 J 220V 1-50HZ 1064nmDiamond Rod Diode Jewelry Laser Welding Machine 100 J 220V 1-50HZ 1064nm


    Applications


    Sporting goods, jewelry, golf head, medical equipment, instrumentation, electronic, mechanical processing, auto, specially used in filling hole on gold and silver jewelry


    Jewelry soldering Samples

    Diamond Rod Diode Jewelry Laser Welding Machine 100 J 220V 1-50HZ 1064nm



    Machine outlook

    Diamond Rod Diode Jewelry Laser Welding Machine 100 J 220V 1-50HZ 1064nm
